AI319043912283en-000103 | 1

Data Sheet

Danfoss Ally™

Radiator Thermostat

Application

The Danfoss Ally™ Radiator Thermostat is a connected radiator thermostat for the residential use.

The Danfoss Ally™ Radiator Thermostat is battery powered, compact and easy to operate with a manual

hand wheel and single button. The Danfoss Ally™ Radiator Thermostat is a Zigbee Certiﬁed Product,

compatible with the Danfoss Ally™ Gateway and with the third party certiﬁed systems using a Zigbee

technology.

The Danfoss Ally™ Radiator Thermostat is easy to install, in just 30 seconds! The adapters are available

for all thermostatic valves manufactured by Danfoss and most other radiator valve manufacturers.

Features:

• Programming and control via a ZigBee gateway

• Energy savings

• Easy to install

• Easy to operate

• The Manual mode

• The Open-window function

• The PID Accurate temperature control

• The Adaptive learning

• Easy to read LCD display

• Display rotation -180 degrees

• Min./max. temp. range

• The Child lock function

• The Frost protection function

• The Valve exercise function

• Backlit display

• Battery life time up to 2 years

• The Visual warning of low battery

• Software upgradeable

Product Language Adapters (included) Code No.

Danfoss Ally™ Radiator Thermostat

EN, DE, DA, FR, IT, PL, CS

RA, M30 014G2420

Danfoss Ally™ Radiator Thermostat

EN, DE, DA, FR, IT, PL, CS

RA, M30, RAV, RAVAL 014G2460

Danfoss Ally™ Radiator Thermostat IT

RA, M30, Caleﬃ, Giacomini

014G2461

Summary of content (5 pages)

PAGE 1
Data Sheet Danfoss Ally™ Radiator Thermostat Application The Danfoss Ally™ Radiator Thermostat is a connected radiator thermostat for the residential use. The Danfoss Ally™ Radiator Thermostat is battery powered, compact and easy to operate with a manual hand wheel and single button. The Danfoss Ally™ Radiator Thermostat is a Zigbee Certified Product, compatible with the Danfoss Ally™ Gateway and with the third party certified systems using a Zigbee technology.
PAGE 2
Data Sheet Specifications Danfoss Ally™ Radiator Thermostat Thermostat type Programmable electronic radiator valve controller Recommended use Residential (pollution degree 2) Actuator Electromechanical Display LCD with white backlight Software classification A Control PID Power supply 2 x 1.5 V alkaline AA batteries Power consumption 3 mW in standby, 1.
PAGE 3
Data Sheet Accessories Danfoss Ally™ Radiator Thermostat Adapter type Code no. For Danfoss RA valves 014G0251 For valves M30 x 1,5 (K) Adapter Valve 014G0252 34 For Danfoss RAV valves 014G0250 26 For Danfoss RAVL valves For Danfoss RTD valves 014G0253 For M28 valves: - MMA - Herz 014G0264 - Comap For Orkli valves 014G0257 For Caleffi and Giacomini valves 014G0263 (Both adaptors supplied) © Danfoss | FEC | 2020.
PAGE 4
Data Sheet Mechanical Installation Danfoss Ally™ Radiator Thermostat 1. Start by mounting the appropriate adapter. Identify the needed adapter from the table on pg 3. 2. I nsert the batteries, then mount the thermostat onto the adapter by turning it until you hear a click. 3. P ress and hold the button for 3 seconds. The Danfoss Ally™ Radiator Thermostat is now mounted and will display the current temperature.
PAGE 5
55 mm 55 mm Dimensions 94 mm 86 mm 55 mm 91 mm with RAV/RAVL valve adapter 55 mm with RA valve adapter 82 mm with M28 valve adapter with M30 valve adapter with Caleffi valve adapter © Danfoss | FEC | 2020.
