H R V – H E AT RECLAIM VENTILATION N=FLAD9LAGF KQKL=EK FX MQ- MF V 1 – OUTDOOR A IR P RO CESSING U NIT VRV ® +EXV-KIT – VRV ® AIR HANDLING APPLICATIONS ooo&\Yacaf&]m A W I D E VA RI E T Y O F D A I K I N S O L U T I O N S F OR THE PROVI S I O N OF FRESH A IR A N D V ENTILATION
<9ACAF =MJGH= FN Daikin has a worldwide reputation based on over 80 years’ experience in the successful manufacture of high quality air conditioning equipment for industrial, commercial and residential use. Daikin Europe N.V.
L9:D= G> ;GFL=FLK INTRODUCTION 2 HRV - HEAT RECLAIM VENTILATION GENERAL HRV (VAM + VKM) FEATURES 5 1. ENERGY EFFICIENCY 6 2. DESIGN FLEXIBILITY 7 3. CLEAN AIR 9 VKM FEATURES 10 1. ENERGY EFFICIENCY 10 2. DESIGN FLEXIBILITY 11 SPECIFICATIONS 13 OPTIONS 20 1. PC BOARD ADAPTER FOR HEATER CONTROL KIT - BRP4A50 21 FXMQ-MFV1 – OUTDOOR AIR PROCESSING UNIT FEATURES 19 1. AIR CONDITIONING AND FRESH AIR TREATMENT VIA A SINGLE SYSTEM 2.
@JN % @=9L J=;D9AE N=FLAD9LAGF ?=F=J9D N9E#NCE! >=9LMJ=K HRV helps create a high quality environment by interlocking with the air conditioning system The Daikin HRV (Heat Reclaim Ventilation) recovers heat energy lost through ventilation and holds down room temperature changes caused by ventilation, thereby maintaining a comfortable and clean environment. This also reduces the load on the air conditioning system and conserves energy.
1. ENERGY EFFICIENCY › Over 30 % Size Reduction Use of the high efficiency paper (HEP) element and optimized design of the fan and airflow passages have resulted in matchless compactness without detriment to the 28% or so reduction in air conditioning load achieved by previous models. A reduction of up to 40mm in height allows the main unit to fit easily into limited spaces such as ceilings.
› Automatic Changeover to Efficient Operation Patterns Operation automatically switches to the optimum pattern to suit prevailing conditions Cooling Heat exchanger element Exhaust fan Damper (heat recovery) EA RA In between (bypass ventilation) EA Heating Heat exchanger element (heat recovery) RA Automatic changeover OA SA Air supply fan EA RA OA SA Automatic changeover OA SA DX coil (heating) DX coil (cooling) Humidifying 2.
› Simple Design and Construction The unit can be installed either horizontally or upside down in accordance with the conditions of the location. A 450mm square inspection hatch enables maintenance and heat exchange element replacement to be performed with ease. Switch box Access door Maintenance cover › 8 Quiet Operation Sound pressure levels are remarkable low at 20.
3. CLEAN AIR › Fresh-Up Operation The user can select between 2 fresh-up modes via the remote control. 1. Supply rich mode: 2. Exhaust fresh-up: Raising the air supply maintains proper room pressure to prevent back-flow of toilet/kitchen odours or moisture inflow. Raising exhaust air decreases room pressure to prevent the leaking of odours or floating bacteria into other rooms.
NCE >=9LMJ=K Exhaust Fan Heat Exchanger Elements EA (Exhaust air to outdours) Damper Motor Damper DX coil (Direct expansion coil) OA (Fresh air from outdoors) RA (Return air from room) SA (Supply air to room) Air Supply Fan Electronics Box (Control box) Float switch Humidifier element: Solenoid valve Utilizing the principle of capillary action, water water is permeated throughout the humidifier element.
Efficient Outdoor Air Introduction with Heat Exchanger and Cooling/Heating Operation Indoor unit with outdoor air treatment. The temperature can be brought close to room temperature with minimal cooling capacity through the use of outdoor air.
KH=;A>A;9LAGFK N9E%>90 Ventilation VAM800FA 150 250 350 500 650 800 1000 1500 ultra-high 74 72 75 74 74 74 75 75 75 high 74 72 75 74 74 74 75 75 75 VAM-FA Temperature exchange efficiency (%) Enthalpy exchange for heating efficiency (%) for cooling Power supply Sound pressure level dB(A) low 79 77 80 77 77 76 76.
NCE%?9E Ventilation, DX coil & humidifier VKM80-100GAM DX coil capacity VKM50GAM VKM80GAM cooling kW 4.71 7.46 VKM100GAM 9.12 heating kW 5.58 8.79 10.
NCE%?9 Ventilation & DX coil VKM80-100GA DX coil capacity VKM50GA VKM80GA cooling kw 4.71 7.46 VKM100GA 9.12 heating kW 5.58 8.79 10.
GHLAGFK Air suction/discharge grille (accessory) Flexible duct (Accessory) High efficiency filter (Accessory) RA SA Round hood (Field supply) Branch duct (Field supply) Silencer ( Accessory) SA Duct (Field supply) Thermal insulation material (Field supply) PC board adapter wiring adapter for electrical appendices KRP2A61 for humidifier (running ON signal output) KRP50-2 for heater control kit BRP4A50 for wiring indoor unit reference installation box for adapter PCB EA OA FXZQ FXFQ FXCQ
1. PC BOARD ADAPTER FOR HEATER CONTROL KIT - BRP4A50 When the installation of an electric heater is required in a cold region, this adapter with an internal timer function eliminates the complicated timer connecting work necessary with conventional heaters. INDOOR RA OUTDOOR EA HRV SA Heater control kit (field supply) OA Temperature thermostat (field supply) (ON when the temperature is at or below -10°C) Temperature thermostat.
Silencer Duct adapter Description VAM150FA VAM250FA VAM350FA High efficiency filter Replacement for air filter YAFM323F15 YAFM323F25 YAFM323F35 YAFF323F15 YAFF323F25 YAFF323F35 Description VAM500FA VAM650FA Silencer reference nom. piping diameter High efficiency filter Replacement for air filter KDDM24A50 Ø 200mm YAFM323F50 VAM1000FA Silencer KDDM24A100 reference nom. piping diameter High efficiency filter Replacement for air filter Duct adapter reference nom.
>PEI%E>N) GML=9LMJ=K Combined fresh air treatment and air conditioning via a single system. Both fresh air treatment and air conditioning can be achieved successfully in a single system via heat pump technology without the usual design problems associated with balancing air supply and discharge.
1. AIR CONDITIONING AND FRESH AIR TREATMENT CAN BE ACCOMPLISHED VIA A SINGLE SYSTEM. Connection Conditions The following restrictions must be observed in order to maintain the indoor units’ connection to the same system. › › The total connected capacity of the standard indoor units and fresh air treatment units must be between 50% and 100% of the capacity of the air conditioning outdoor units.
KH=;A>A;9LAGFK >PEI%E>N) Ventilation FXMQ200-250MFV1 Capacity Power Input FXMQ125MFV1 FXMQ200MFV1 FXMQ250MFV1 cooling kW 14.0 22.4 28.00 heating kW 8.9 13.9 17.40 cooling kW 0.359 0.548 0.638 heating kW 0.359 0.548 0.
GHLAGFK FXMQ125MFV1 Description Filters Filter chamber *1 KAFJ371L140 KAFJ371L280 KAFJ372L140 KAFJ372L280 90% KAFJ373L140 KAFJ373L280 KDJ3705L140 KDJ3705L280 Drain pump kit Adapter for wiring Notes : *1 Filter chamber has a suction-type flange. (Main unit does not). Dimensions and weight of the equipment may vary depending on the options used. Some options may not be usable due to the equipment installation conditions. Please confirm prior to ordering.
;GFLJGD KQKL=EK HRV / FXMQ-MFV1 can also be connected to Operation of the air conditioner using the remote control is interlocked with HRV operation, greatly simplifying overall system control. The same remote control centralizes air conditioning and ventilation operations, obviating any need for ventilation remote control installation work. Using a centralized remote control also frees the user to choose from a wide range of control systems that integrate air conditioning and ventilation.
5 individual control systems give the user control over the VRV® system and the combined ventilation. BRC1D52 is a wired remote controller giving access to room temperature settings, schedule timer, … Next to that it also has got user friendly HRV functions. BRC301B61 is a wired controller especially designed for VAM units. BRC2C51 and BRC3A61 are compact, easy to use remote controllers, ideal for use in hotel bedrooms.
2.
A variety of control systems can be controlled using only the BRC1D52 ( HRV only) › Group Control One air conditioner remote control simultaneously controls up to 16 air conditioning and HRV units. Up to 16 units*1 HRV Up to 500m BRC1D52 *1: Count VKM unit as two air conditioners. For details, see Table 1 on page 15. › Control using 2 remote controls Allows control of air conditioning and HRV units from two locations by connecting two air conditioner remote controls.
SYSTEM CHARACTERISTICS INDEPENDENT OPERATION › Air conditioner remote control can be used STANDARD SYSTEM BRC1D52 BRC301B61 BRC1D52/BRC301B61 HRV HRV › Operation is possible using 2 remote controls › Multiple HRV units can be simultaneously con-trolled in batch. (Up to 8 HRV units can be connected) BRC1D52(No.
Note: › › › › Group control is not possible between FXMQ-MFV1 and standard type indoor units. Connect remote controllers to each unit. Not all FXMQ-MFV1 functions are available when using centralised control. Please refer to your local installer for detailed information. The remote control wired to the FXMQ-MFV1 cannot be set as master remote control. Otherwise, when set to ‘auto’, the operation mode will switch according to outdoor air conditions, regardless of indoor temperature.
SYSTEM CHARACTERISTICS NECESSARY ACCESSORIES Unified ON/OFF control DCS301B51 › One control can control the on/off operation of 16 groups of units collectively or individually BATCH / INDIVIDUAL CONTROL SYSTEM HRV Indoor unit BRC1D52 DCS301B51 DST301B51 BRC1D52 Indoor unit › Up to 8 controls can be installed in one centralised transmission line (in one system), which enables control of up to 128 groups.
NJN#=PN%CAL NJN 9AJ @9F=9LMJ=K Daikin has introduced a new range of R-410A inverter condensing units to provide ventilation and air conditioning for air handling installations in medium and large commercial spaces. This system is unique because it combines the flexibility of Daikin VRV® units with Air Handling Applications. Because of the simplicity of the system, it is very easy to design the air conditioning system. 1.
2. LARGE RANGE OF EXPANSION VALVE KITS (EXV) POSSIBLE Allowed Heat Exchanger Volume (dm3) min max Capacity Class Allowed Heat Exchanger Capacity (Kw) min std max EKEXV 50 0.76 - 0.96 5.0 5.6 6.2 EKEXV 63 0.96 - 1.22 6.4 7.1 7.8 EKEXV 80 1.22 - 1.53 8.1 9.0 9.9 EKEXV 100 1.53 - 1.91 10.1 11.2 12.3 EKEXV 125 1.91 - 2.14 12.6 14.0 15.4 EKEXV 140 2.14 - 3.06 14.4 16.0 17.6 EKEXV 200 3.06 - 3.82 20.2 22.4 24.6 EKEXV 250 3.82 - 4.78 25.2 22.0 30.
2.
;GFLJGD KQKL=EK 1. CONTROL OF AIR TEMPERATURE VIA DAIKIN CONTROL ON / OFF KRP4A51 Ts Daikin control box: EKEXMCB BRC1D52 Te AHU TR Td Room Set point can be fixed via standard Daikin wired remote controller. Remote ON/OFF can be achieved by an optional adapter KRP4A51. No external DDC controller should be connected. BRC1D52 is used to set the set point temperature (connected to the EKEXMCB).
NOTES 35
Daikin Europe N.V. is approved by LRQA for its Quality Management System in accordance with the ISO9001 standard. ISO9001 pertains to quality assurance regarding design, development, manufacturing as well as to services related to the product. ISO14001 assures an effective environmental management system in order to help protect human health and the environment from the potential impact of our activities, products and services and to assist in maintaining and improving the quality of the environment.
