SiBE12-713 Function of Main Structural Parts
Function and Control 77
2. Function of Main Structural Parts
2.1 Main Structural Parts
Heat Pump Model
Cooling Only
Model
Note: Expansion Valve : In Case of 2 port model.....EVA-B, 3 port model.....EVA-C,
4 port model.....EVA-D
Four way valve
Compressor
EVB
EVC
EVD
EVA
Expansion valve
(R5066)
Compressor
EVB
EVC
EVD
EVA
Expansion valve
(R4596)
