Specifications SiBE12-713
28 Specifications
50Hz 230V
Model
FTXS35CAVMB
Cooling Heating
Rated Capacity 3.5kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 8.1 (286)
M 6.0 (212) 6.7 (237)
L 4.4 (155) 5.3 (187)
SL 3.8 (134) 4.6 (162)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325
Weight kg 7.5
Gross Weight kg 11
Operation
Sound
H/M/L/SL dBA 39/33/26/23 39/34/29/26
Sound Power H dBA 57 57
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
Drain mm
φ
18.0
Drawing No. 3D050945
Model
FTXS50FV1B FTXS60FV1B
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 14.7 (519) 16.1 (569) 16.2 (572) 17.4 (614)
M 12.4 (438) 13.9 (491) 13.6 (480) 15.1 (533)
L 10.3 (364) 11.5 (406) 11.4 (403) 12.7 (448)
SL 9.5 (335) 10.2 (360) 10.2 (360) 11.4 (403)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15 0.16 0.18 0.20
Power Consumption (Rated) W 34 36 40 45
Power Factor % 98.6 97.8 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 43/39/34/31 42/38/33/30 45/41/36/33 44/40/35/32
Sound Power H dBA 59 58 61 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D056019 3D056020
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
