Specifications SiBE12-713
26 Specifications
50Hz 230V
Model
FTXS25D3VMW FTXS25D3VML
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 2.5kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 9.4 (332) 8.7 (307) 9.4 (332)
M 6.7 (237) 7.6 (268) 6.7 (237) 7.6 (268)
L 4.7 (166) 5.8 (205) 4.7 (166) 5.8 (205)
SL 3.9 (138) 5.0 (177) 3.9 (138) 5.0 (177)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.16 0.16 0.16 0.16
Power Consumption (Rated) W 35 35 35 35
Power Factor % 95.1 95.1 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 38/25/22 38/28/25 38/25/22 38/28/25
Sound Power H dBA 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051087 3D051088
Model
FTXS35D3VMW FTXS35D3VML
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 3.5kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.9 (314) 9.7 (342) 8.9 (314) 9.7 (342)
M 6.9 (244) 7.9 (279) 6.9 (244) 7.9 (279)
L 4.8 (169) 6.0 (212) 4.8 (169) 6.0 (212)
SL 4.0 (141) 5.2 (184) 4.0 (141) 5.2 (184)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 39/26/23 39/29/26 39/26/23 39/29/26
Sound Power H dBA 57 57 57 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051089 3D051090
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
