SiBE12-713 Specifications
Specifications 25
50Hz 230V
Model
CTXG50EV1BW CTXG50EV1BS
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 5.0kW Class
Front Panel Color Mat Crystal White Mat Crystal Silver
Air Flow Rates
m³/min
(cfm)
H 11.3 (398) 12.6 (444) 11.3 (398) 12.6 (444)
M 9.1 (320) 10.6 (373) 9.1 (320) 10.6 (373)
L 7.1 (250) 8.7 (306) 7.1 (250) 8.7 (306)
SL 6.7 (236) 7.7 (271) 6.7 (236) 7.7 (271)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30 30 30 30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 47/41/35/32 47/41/35/32 47/41/35/32 47/41/35/32
Sound Power H dBA 64 64 64 64
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051105 3D051106
Model
FTXS20D3VMW FTXS20D3VML
Cooling Heating Cooling Heating
Rated Capacity 2.0kW Class 2.0kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 9.4 (332) 8.7 (307) 9.4 (332)
M 6.7 (237) 7.6 (268) 6.7 (237) 7.6 (268)
L 4.7 (166) 5.8 (205) 4.7 (166) 5.8 (205)
SL 3.9 (138) 5.0 (177) 3.9 (138) 5.0 (177)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.16 0.16 0.16 0.16
Power Consumption (Rated) W 35 35 35 35
Power Factor % 95.1 95.1 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 38/25/22 38/28/25 38/25/22 38/28/25
Sound Power H dBA 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051085 3D051086
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
