Troubleshooting Based on Equipment Condition Si42-107
78 Troubleshooting
1 #=5;@
%":"+"
/,*
:"
! 600
! 0(
! 60060)6.
4:";
Correction of installation
Reinforcement for ceilings or
Insert shock absorber in
mounting section, or strengthen
the mounting section.
Normal. The sound is flushing
noise of gas (refrigerant) inside
air conditioning unit
Insert cushion materials to the
pipe support such as saddle.
Normal. The noise is a sound
generated at the time of gas
Disassemble and remove parts
contact.
Normal. Operation sound of
draining device
Correct piping manually or attach
a dead weight to pipe
Normal.
After vacuum drying, charge
correct amount of refrigerant.
* Excess charge of
refrigerant
* Air intrudes into
refrigerant system
* Flushing noise due to
refrigerant shortage.
(Sound of shoo...)
NO
YES
Does the
noise generate with
vibration of whole
ceilings and
walls?
YES
NO
NO
NO
Does the
noise generate
with vibration of
unit mounting
section?
Continuous
slight noise of "shoo....."
during cooling
operation
YES
YES
[Power supply side]
Is the
piping secured?
Sound
of "shoo..."
generates just after
operation start
or stop.
YES
NO
NO
Does the fan
contact with other
parts?
Sound
of "shoo..." generates
during cooling or after
operation
stop.
NO
Does the
pipe contact with
casing?
YES
NO
YES
YES
NO
Is
the noise
flushing sound from
pressure reducing
valve or capillary
tube?
YES
[Installation work side]
(P1275)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
