How to Handle Request for Maintenance Si42-107
70 Troubleshooting
)!)"=+
'"!;
6060669
(6(
YES
NO NO
Cooling
NO
NO
YES
Runs
Runs
Nomal
Nomal
Doesn't run
YES
YES
(Maintenance required)
OK.We'll be right over.
(P1268)
Turn the power supply
switch ON or replace
the fuse.
Wait until
power failure
is over.
Is there a
power
failure?
Doesn't run at all
The power supply switch is
OFF or the switch's fuse is
burnt.
Set the remote
controller's temperature
setting to:
(1)When
cooling:Minimum
(2)When
heating:Maximum
The fan comes on
but the
compressor
doesn't run.
Cooling starts but
stops right away.
Try turning the
Operation switch OFF
and On.
The unit won't run
again for a while
after stopping.
The unit runs but
doesn't cool the
room.
Measure the suction
/disharge temperature.
Did you allow 3 minutes to
elapse after turning ON?
Is there something causing the
indoor load to be large, such as
an open window or door?
(Temperature differential
=suction temperature - discharge temperature)
Operation is
normal.
Temperature
differential is 8~18˚C
(1) The operation circuit fuse is
disconnected or is making poor contact.
(2) The operation swich is broken or its
contact is defective.
(3) The high pressure switch is broken.
(4) The fan motor's magnetic switch is
broken.
(5) The fan motor's protection thermostat is
being actuated or is broken.
(6) The compressor's overcurrent relay is
broken.
(7) The compressor's protective thermostat
is broken.
(8) The electrical system insulation is
defective.
(9) The compressor's magnetic switch's
contact is defective.
(10) The compressor is broken.
(11)
Thermostat is broken.
(12) The cool/heat selector is broken.
(13) The operation switch is broken.
(14) The compressor's magnetic swich is
broken.
(15)
Over-charged with refrigerant.
(16)
Air is mixed inside the refrigerant
circuit.
(17)
The pressure switch is broken.
(18)
The outdoor unit fan motor's magnetic
switch is broken.
(19)
The outdoor unit fan motor's auxiliary
relay is broken.
(20) The outdoor unit's heat exchanger is
dirty.
(21) There is something blocking the
outdoor unit's air flow.
(22) Malfunction of the outdoor unit's fan.
(23) Overcurrent relay (for compressor)
(24) Compressor's protective themostat
(25) The causes for the overcurrent relay
(for compressor) being actuated are:
(26)-1 Power supply voltage is lower than
prescribed.
(26)-2 High pressure is too high.
(26)-3 The power supply cord is too small.
(26)-4 The compressor is broken.
(27) The causes for the compressor's
protective thermostat
(27)-(1) Unsatisfactory compression from
the compressor
(27)-(2) Defective refrigerant
(27)-(3)
Unsatisfactory refrigerant circulation
