Operation Flow Chart Si42-107
60 Funciton and Operation
&'"!;6',7-C7-8
∗ :6/!$A!*7'5!$A!*
/*?/!*;6(
VW
One of the safty device Q1RP,
F1C, S1B, S1PH, Q1L, Q2L
acutuates.
Relay K1R of outdoor unit is OFF.
Relay K2R, K3R, of indoor unit is
OFF then K2M and K1M are OFF.
Fan and compressor are OFF.
Safty device returns to normal
condition.
Is safty
device in normal
condition.
YES
Power switch ON.
Thermostat
ON judgement.
Mgs K1M of outdoor unit is ON,
then compressor and outdoor fans
operates.
NO
Relay K1R of outdoor unit is ON.
Relay K2R, K3R of indoor
unit are ON.
Press Fan operation button.
Mgs K2M of indoor unit is ON,
and relay K2R, K4R are ON.
Indoor Fan operates.
Press cooling button.
Thermostat OFF
Unit does not
operate.
Thermostat ON
