Operation Flow Chart Si42-107
58 Funciton and Operation
&'"!;
&'"!;6',7-C7'8
VW
Is F1C
of indoor unit in
normal condition.
YES
Power switch on remote controller ON.
Thermostat
ON judgement.
Mgs K1M of outdoor unit is ON,
then compressor and outdoor fans
operates.
NO
Relay K1R of indoor unit is ON
Press Fan operation button.
Mgs K1M of indoor unit is ON.
Indoor unit Fan operates.
Press cooling button.
One of safty device Q1L, Q2L and
S1B actuates.
Mgs K1M of outdoor unit is OFF.
Compressor and outdoor fans are
OFF. (Indoor fan keeps to operate.)
Safty device returns to normal.
Stop unit operation
and locate cause
of actuation of
safty device.
Manually resets the safty devices.
Thermostat OFF
Unit does not
operate.
Thermostat ON
(P1261)
