Si42-107 Troubleshooting Based on Equipment Condition
Troubleshooting 213
'&?:5
%":"+"
/>,*).
#,
+;
#D
:"
! (
! (06(
4:";
Make the following
temperature setting using
remote controller.
(1) Cooling: Lowest setting
(2) Heating: Highest setting
Possibly faulty electric
components
Normal.
Diagnose based on error code on
remote controller.
Equipment cannot be operated in
this condition.
Check electric components.
Does
equipment operate?
Is
operation lamp
on remote controller
flashing?
Is outside
temperature above
allowed operating
range?
Is operation
lamp on indoor unit
located near wireless
remote controller signal
receiving section
flashing?
YES
NO
NO
NO
NO
YES
YES
YES
YES
(P1357)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
