Specifications

Easy Installation High reliability
High external static pressure of 78.4 Pa
High external static pressure has been achieved thanks to the fan grilles
and the dual DC fans that reduce internal pressure loss. Daikin offers 78.4
Pa (8 mm H
2O) external static pressure by field setting to meet the
requirements for installation on each floor.
VRVIII single outdoor unit series enables a mixed combination of VRV and residential indoor units by
connecting BP units. As many as 29 indoor units can be connected, making this series a highly versatile
system.
78.4 Pa
Small and light, significantly reducing
constraints during carry-in
Carry-in possible using
ordinary elevators
Can be carried on a
fork-lift without a pallet
Easy belt
suspension
Automatic test operation
Simply press the test operation button and the unit
performs an automatic system check, including
wiring, shutoff valves, and sensors. The results are
returned automatically after the check finishes.
Backup operation
If one of the multiple compressors malfunctions, the
other compressors take over for emergency operation.
*1
Less chances of refrigerant leakage
The shutoff valve connections for outdoor unit
are brazed, meaning less chance of refrigerant
leakage compared with flanged or flared
connections.
*1. Possible only with single outdoor unit systems that are
equipped with two or more compressors. Local setting of
the outdoor unit is necessary.
If one compressor
malfunctions...
Emergency operation occurs.
*1
Note: Total capacity index of connectable indoor units must be 50%–130% of the capacity index of the outdoor unit.
Refer to page 34 for the maximum number of connectable indoor units.
Indoor
units
29
Max.
8
As many as 29 indoor units can be connected
VRV indoor units
Residential indoor units
BP unit BP unit
