Specifications

Slim Ceiling Mounted Duct Type
22
Slim and smooth design suits your shallow ceiling
700 mm width type
900/1,100 mm width type
Signals from the wireless remote controller are
transmitted to the signal receiver.
240 mm
200 mm
Only 700 mm
FDKS-EA
Dimensions (H x W x D)
Weight
Airflow rate (H)
External static pressure
200 x 700 x 620 mm
21 kg
8.7 m
3
/min
30 Pa
200 x 900 x 620 mm
25 kg
40 Pa
FDKS25EA FDKS35EA FDKS25CA
FDKS35CA
9.5 m
3
/min 10 m
3
/min
FDKS25
35/31/29 dB (A)
FDKS35
35/31/29 dB (A)
FDKS50
37/33/31 dB (A)
FDKS60
38/34/32 dB (A)
(H/L/SL)
Low operation sound level
Home Leave Operation prevents large rises or
falls in the indoor temperature by continuing
operation* while you are sleeping or out of your
home. This means that an air-conditioned
welcome awaits when you wake or return. It also
means that the indoor temperature can quickly
return to your favourite comfort setting.
Models in the FDKS-EA series are only 700 mm
in width and 21 kg in weight, so are easily
installed in limited spaces. Just 200 mm in height,
all models can be installed in rooms with as little
as 240 mm depth between the drop ceiling and
ceiling slab, making them ideal for even shallow
ceilings.
Notes:
1. To prevent an increase in operation noise, avoid
installing the air suction grille directly below the
suction chamber.
2. Grilles, piping connections, ducts, and installation
parts should be obtained locally. Slim Ceiling
Mounted Duct type FDKS models do not have
drain-up pumps.
3. The signal receiver unit must be located near the
air suction inlet, because the unit includes a
sensor that detects room temperature.
Suction grille (KDGF19A45)
Option
* Locally obtained parts
AIR
Air suction
grille*
Suction duct*
Signal
receiver
Air discharge duct*
Suspension bolt*
Air discharge grille*
Signal receiver wire
Length
=
1,900 mm
Chamber
AIR
Air filter
* Home Leave Operation can be selected for any temperature from 18 to
32˚C for cooling operation and 10 to 30˚C for heating operation.
* Home Leave Operation function must be set using the remote controller
when going to sleep or leaving the house, and after waking up or returning
home.
Standard accessory
Note: Remote controllers
other than the standard
accessory wireless remote
controller cannot be used.
FDKS25EA/FDKS35EA
FDKS25CA/FDKS35CA/FDKS50C/FDKS60C
Great for
hotel use!
