Specifications

12
Slim design for flexible installation
Main body
Air discharge grille
(Option)
Set for front discharge using a suspended ceiling.
Downward discharge is shut off and air is blown straight out
(front discharge).
Front discharge is possible with an air
discharge unit (option), which allows the
installation in the drop-ceiling or sagging wall.
Single-flow type allows effective air discharge
from corner or from drop-ceiling.
Providing 3 different settings of standard, draft
prevention and ceiling soiling prevention, the
auto swing mechanism realises even
distribution of airflow and room temperature.
Main body
Downward discharge
Air discharge grille (Option)
3
32˚C
30˚C
28˚C26˚C
24˚C
22˚C
20˚C
2
1
0
123456 (m)
(m)
500 mm
Drain pump is equipped as standard
accessory with 500 mm lift.
Slim body needs only 220 mm space above the
ceiling. If you use a panel spacer (option), the
unit can be installed in the minimum space of
195 mm.
A long-life filter (maintenance free up to one
year*) is equipped as standard accessory.
Panel spacer
20 mm
Min.195 mm
Ceiling Mounted Cassette Corner Type
FXKQ25MA/FXKQ32MA
FXKQ40MA/FXKQ63MA
* Remote controllers are an optional accessory.
Refer to page 39 for remote controller details.
* 8 hr/day, 25 day/month. For dust concentration of 0.15 mg/m
3
