Specifications

9
360° airflow improves temperature distribution
and offers a comfortable living environment.
FXFQ25P/FXFQ32P/FXFQ40P
FXFQ50P/FXFQ63P/FXFQ80P
FXFQ100P/FXFQ125P
Note: Whatever the discharge direction, the same type of panel is used. If installing for other than all-round flow, an air discharge outlet sealing member (option) must be used to close each unused outlet.
3-way flow L-shaped 2-way flow All-round flow 4-way flow
850 mm
The industry’s first* Round Flow Ceiling Mounted
Cassette type offers 360° airflow with improved
temperature distribution.
All models are lighter than the conventional ones.
Ex: Models FXFQ25P-50P are 4.5 kg lighter
(reduced from 24 kg to 19.5 kg).
A modern sophisticated decoration panel has
been applied, with a panel surface that has been
treated with a dirt-repellant coating.
An antibacterial treatment that uses silver ions
has been applied to the drain pan, preventing
the growth of slime, mould and bacteria that
cause blockages and odours.
The horizontal louvres prevent dew
condensation. Their non-flocking surfaces, which
repel dirt, are easy to clean.
The air filter has an anti-mould and antibacterial
treatment that prevents the growth of mould
generated from dust or moisture that may
adhere to the filter.
Example of airflow patterns:
360° airflow is available, as well as 2- to
4-way flows, so you can choose the most
suitable airflow pattern depending on
location or room layout.
Drain pump is equipped as
standard accessory, and the
lift height has been improved
from 750 mm to 850 mm.
Treated surface Untreated surface
Resists
soiling
• Condition after
exposure to the
smoke of 600
cigarettes in 1 m
3
enclosed space.
Dirt and
grime
Control of the airflow rate has been improved
from 2-step to 3-step control.
4-way flow
Round Flow
There are areas of
uneven temperature.
There are much fewer
areas of uneven temperature.
* As of April 2004, the release date for Japan.
Indoor Unit Lineup
Low operation sound level
(dB(A))
44/39/34
125
43/37.5/32
100
36/33.5/31
80
34/31/28
63
32/29.5/27
50
31/29/27
4025/32
30/28.5/27
Sound
level
(HH/H/L)
FXFQ-P
VRV Indoor Units
Ceiling Mounted Cassette (Round Flow) Type
* Remote controllers are an optional accessory.
Refer to page 39 for remote controller details.
