User's Manual

Setting 90
You have set up preset spots or tunnels’ smart plan. See "4.4.1 Configuring Smart Plan" for
detailed operations.
Procedure
Select Setting > Smart Thermal > IVS > IVS. Step 1
The IVS interface is displayed.
Select a preset in Preset bar. Step 2
The camera turns to the position.
This step is required only when preset dot function is carried on this interface.
Set up area invasion rules. Step 3
1) Click and then double-click the rule you have just added to set up its name.
Select Area Invasion as the type. See Figure 4-44.
Intrusion Figure 4-44
2) Click Draw Rule to draw a monitoring area on surveillance image. Right-click to
end drawing.
 It requires certain residence time and moving space for the target to be
confirmed, so leave some space around warning area during configuration
and do not set it near obstacles.
 In Rule Type bar, when you select Cross/Inside, you need to modify your rule
box to leave some detecting area around the box.
