User's Manual

Setting 89
Parameters
Description
Direction
Configure the target moving direction for tripwire alarm, you can select
A->B, B->A and A<->B.
Record
Enable this function and alarm recording will be triggered when there is
an alarm.
 To check and reset recorded videos’ storage path, see "4.1.2.5
Configuring Storage Path".
 Two more conditions must be satisfied before alarm recording
function works:
 You have enabled motion detection recording. See "4.7.1.1
Configuring Video Recording" for detailed operations.
 You have enabled auto recording. See "4.7.3 Configuring
Record Control Parameters" for detailed operations.
Record Delay
The record keeps running for the set time after alarm is ended.
Relay-out
You can connect this relay-out port to such alarm devices as flashlights
and alarm whistles. When an alarm is triggered, alarm devices
connected to the relay-out port will work. Select the check box to enable
this function.
Alarm Delay
The Alarm linkage keeps running for the set time after alarm is ended.
Send email
Enable this function. An e-mail will be delivered to the device user once
the alarm is triggered.
Set your e-mail first before enabling this function. See "4.2.5 Configuring
SMTP" for detailed operations.
PTZ
Select the check box of PTZ and select an item from None, Preset,
Tour, and Pattern in the Activation bar. Once an alarm is triggered, your
PTZ will execute the item you have selected in the Activation bar.
Set up PTZ first before enabling this function. See "3.2 PTZ" for detailed
operations.
Snapshot
Enable this function and Snapshot will be triggered once there is an
alarm.
 To check and set snapshots’ storage path, see "4.1.2.5 Configuring
Storage Path".
 Enable motion-detecting snapshots first before enabling this
function. See "4.7.1.2 Configuring Snapshot" for detailed operations.
Click OK to finish configuration. Step 4
4.4.2.2.2 Configuring Intrusion
When a target is crossing or appears in the area you have set up, an alarm is triggered.
Preparation
