User's Manual

Setting 125
Parameter
Description
Atmospheric
Temperature
Temperature of our environment. Ranges from -50 °C to 327.7 °C .
Target Radiation
Coefficient
Set Radiation coefficient of targets that are shot by this Device.
Ranges from 0.5 – 1.
Target Distance
Distance from the camera to targets that are shot. Ranges from 0m
– 10000m.
Target Reflection
Temperature
Temperature of targets that are shot by this Device. Ranges from
-50 °C to 327.7 °C .
Isotherm
Select the On check box.
You have to make sure that floor temperature <= median
temperature <= ceiling temperature <= saturation temperature.
Min Limit
Temperature
When gain mode is under low-temperature mode, value ranges

from -40 °C to 150 °C .
When gain mode is under high-temperature mode, value

ranges from -40 °C to 600 °C .
Medium
Temperature
When gain mode is under low-temperature mode, value ranges

from -40 °C to 160 °C .
When gain mode is under low-temperature mode, value ranges

from -40 °C to 600 °C .
Max Limit
Temperature
When gain mode is under low-temperature mode, value ranges

from -40 °C to 160 °C .
When gain mode is under low-temperature mode, value ranges

from -40 °C to 600 °C .
Saturation
Temperature
When gain mode is under low-temperature mode, value ranges

from -40°C to 160℃.
When gain mode is under low-temperature mode, value ranges

from -40 °C to 600 °C .
Color Code
Select On to enable color code.
A color code will be represented on the right side of surveillance
images.
Click Save to finish configuration. Step 3
Effect images are as shown in Figure 4-69, Figure 4-70, and Figure 4-71.
