User's Manual

Setting 121
Parameter Figure 4-64
Configure temperature measuring rules and then parameters. Step 2
1) Click to add a rule.
See Figure 4-65.
Rule adding Figure 4-65
2) Double-click the rule you have just added to select measurement items and modify
the measurement name.
3) Draw your rules.
Select Measurement Items as Spot, and you can click a position on the 
surveillance image and a spot is formed.
Select Measurement Items as Line, Rectangle or Ellipse, and you can hold 
the left mouse button to draw rules you need on the surveillance image.
Select Measurement Items as Polygon, and you can hold the left mouse 
button to draw rules you need on the surveillance image. Right-click to end
your drawing.
Select a rule you have drawn and click Redraw Rule. Then you can delete the rule
and draw a new one.
4) Select the Open Local Config check box and configure parameters. See Table
4-37 for details.
Table 4-37 Parameter description of local configuration
