Setting 112
Parameters
Description
Period
Define a period during which the alarm settings are active.
1. Click Setting, and the period setting interface is displayed.
2. Configure period.
Method 1: Hold down and drag the left mouse button to select
working period you need.
Method 2: Select Setting > Event > Video Detection and click
Setting on the right side of Period. An interface is displayed. In
this interface, there are seven Settings altogether each of which
corresponds to a day in a week. Select a Setting you want and
there are six periods (period1-period6) below for you to pick up.
3. Click Save to finish configuration of working period.
Anti-Dither
The system records only one audio detection event within the set time.
Record
Enable this function and alarm recording will be triggered when there is
an alarm.
To view and set storage path of recorded videos, see "4.1.2.5
Configuring Storage Path".
The following two conditions must be satisfied before alarm
recording function works:
You have enabled motion detection recording. See "4.7.1.1
Configuring Video Recording" for detailed operations.
You have enabled auto recording. See "4.7.3 Configuring
Record Control Parameters" for detailed operations.
Record Delay
Set a length of time for the Device to delay turning off recording after an
alarm is ended.
Relay-out
You can connect this relay-out port to such alarm devices as light and
siren. When an alarm is triggered, those alarm devices will work. Select
the check box to enable this function.
Alarm Delay
Set a length of time for the Device to delay turning off alarm after an
event is actually ended.
Send Email
Select the Send Email check box and an e-mail will be delivered to the
device user once an alarm is triggered.
Set your e-mail first before enabling the Send Email function. See "4.2.5
Configuring SMTP" for detailed operations.
PTZ
Select the check box of PTZ and select an item from None, Preset, Tour,
and Pattern in the Activation bar. Once an alarm is triggered, your PTZ
will execute the item you have selected in the Activation bar.
Set PTZ first before enabling this function. See "3.2 PTZ" for detailed
operations.
