Setting 100
Set rules of fire warning. Step 4
1) Select fire warning mode on your own needs.
High response mode is your only option when you want your camera to detect any
a hidden fire danger.
Anti-jamming: Your camera will only detect those objects that are newly with
high temperature and send off alarms. That means under Anti-jamming
mode, a constantly high-temperature object (a boiler, for example) is
excluded.
High Response: Your camera will detect any a hidden fire danger and send
off alarms.
2) Select a color in . Each color represents a certain area which
you can draw with your left mouse button. You can also give a name to the area
you have drawn and set its sensitivity.
The larger the sensitivity is, the easier a fire will be triggered.
3) Set up fire warning parameters. See Table 4-27 for details.
Table 4-27 Fire warning parameters
Parameter
Description
Period
Define a period during which the alarm settings are active.
1. Click Setting, and the period setting interface is displayed.
2. Configure period.
Method 1: Hold down and drag the left mouse button to select
working period you need.
Method 2: Select Setting > Event > Video Detection and click
Setting on the right side of Period. An interface is displayed. In
this interface, there are seven Settings altogether each of
which corresponds to a day in a week. Select a Setting you
want and there are six periods (period1-period6) below for you
to pick up.
3. Click Save to finish configuration of working period.
Duration
The shortest time from placing an object in the detection area to an alarm
is triggered.
Record
Enable this function and alarm recording will be triggered when there is
an alarm.
To view and set storage path of recorded videos, see "4.1.2.5
Configuring Storage Path".
The following two conditions must be satisfied before alarm
recording function works:
You have enabled motion detection recording. See "4.7.1.1
Configuring Video Recording" for detailed operations.
You have enabled auto recording. See "4.7.3 Configuring
Record Control Parameters" for detailed operations.
