Setting 94
An alarm is triggered only when size of abandoned objects lies between the
two filter boxes.
When drawing a rule, you can select Max Size or Min Size and click Clear to
delete a relevant filter box.
4) Configure abandoned object parameters. See Table 4-24 for details.
Table 4-24 Abandoned object parameters
Parameter
Description
Period
Define a period during which the alarm settings are active.
1. Click Setting, and the period setting interface is displayed.
2. Configure period.
Method 1: Hold down and drag the left mouse button to select
working period you need.
Method 2: Select Setting > Event > Video Detection and click
Setting on the right side of Period. An interface is displayed. In
this interface, there are seven Settings altogether each of
which corresponds to a day in a week. Select a Setting you
want and there are six periods (period1-period6) below for you
to pick up.
3. Click Save to finish configuration of working period.
Duration
The shortest time from placing an object in the detection area to an alarm
is triggered.
Record
Enable this function and alarm recording will be triggered when there is
an alarm.
To view and set storage path of recorded videos, see "4.1.2.5
Configuring Storage Path".
The following two conditions must be satisfied before alarm
recording function works:
You have enabled motion detection recording. See "4.7.1.1
Configuring Video Recording" for detailed operations.
You have enabled auto recording. See "4.7.3 Configuring
Record Control Parameters" for detailed operations.
Record Delay
Set a length of time for the Device to delay turning off recording after an
alarm is ended.
Relay-out
You can connect this relay-out port to such alarm devices as light and
siren. When an alarm is triggered, those alarm devices will work. Select
the check box to enable this function.
Alarm Delay
Set a length of time for the Device to delay turning off alarm after an
event is actually ended.
Send Email
Select the Send Email check box and an e-mail will be delivered to the
device user once an alarm is triggered.
Set your e-mail first before enabling the Send Email function. See "4.2.5
Configuring SMTP" for detailed operations.
