You have set at least two temperature testing rules. See "4.6.1.1Configuring Temperature
Measuring Rules" for detailed operations.
Procedure
Select Setting > Temperature > Rule > Temp Contrast. Step 1
The Temp Contrast interface is displayed. See Figure 4-66.
Temperature contrast Figure 4-66
Set temperature contrast rules Step 2
1) Click to add a temperature contrast rule.
See Figure 4-67.
Temperature contrast rules adding Figure 4-67
2) Double-click to add a temperature contrast rule.
3) Set alarm parameters. See Table 4-39.
Table 4-39 Parameters
Parameters
Description
Alarm Results
You can select from the following three options to determine a
standard of triggering an alarm.
Average temperature: Compare average temperatures of two

rules.
Maximum temperature: Compare maximum temperatures of

two rules.
Minimum temperature: Compare minimum temperatures of

two rules.
When one of the two rules refers to a spot, both maximum
temperature and minimum temperature are actually average
temperature.
