Service manual

2-2-3) SERVICE SCHEDULE FOR EACH PARTS

Following parts should be checked according to the recommanded intervals.

: Check and Replace if necessary. : Replace

PERIODIC SERVICE (TIME)

NAME

1000 2000 3000 4000 5000

DRUM TOTAL ASS'Y

CAPSTAN MOTOR

L/C BRKT TOTAL ASS'Y

REEL BELT

IDLER PLATE TOTAL ASS'Y

REEL TABLE

T BRAKE ASS'Y

TENSION BAND ASS'Y

PINCH LEVER TOTAL ASS'Y

AC HEAD ASS'Y

FE HEAD

REEL GEAR TOTAL ASS'Y

Note: Even though the unit is not used frequently, cleaning, lubrication and replacement of the belt

should be undertaken every 2 years.
