Service manual

PARTS SLIST

LOC. PARTS CODE PARTS NAME PARTS DESCRIPTION

PAL

M1000 PVDKARP82S VCR DECK AS(T40) DRP-8200HVP(N82S-C)N/H/C (2HD SP/LP NON-DLC)

PVDKARP84S VCR DECK AS(T40) DRP-8400HVP(N82S-C)N/H/C(4HD SP/LP NON-DLC)

PVDKARP86S VCR DECK AS(T40) DRP-8600HVP(N82S-C)N/H/C(6HDHI-FINON-DLC)

SECAM

M1000 PVDKARP82S VCR DECK AS(T40) DRP-8200HVP(N82S-C)N/H/C(2HD SP NON-DLC)

PVDKARS84S VCR DECK AS(T40) DRS-8400HVP(N82S-C)N/H/C(4HD SP/LP NON-DLC)

PVDKARS86S

VCR DECK AS(T40) DRS-8600HVP(N82S-C)N/H/C(6HD HI-FI NON-DLC)

7-1. Parts List of Deck Total ASS’Y

7-2. Parts List of Drum Price ASS’Y

LOC. PARTS CODE PARTS NAME PARTS DESCRIPTION

PAL

AD001 97PA283101 DRUM PRICE AS CYP-T210V( 2HD SP/LP NON-DLC)

97PA283201 DRUM PRICE AS CYP-T410V( 4HD SP/LP NON-DLC)

97PA283601 DRUM PRICE AS CYP-T610V( 6HD HI-FI NON-DLC)

SECAM

AD001 97PA283101 DRUM PRICE AS CYP-T210V( 2HD SP NON-DLC)

97PA283301 DRUM PRICE AS CYS-T410V( 4HD SP/LP NON-DLC)

97PA283501 DRUM PRICE AS CYS-T610V( 6HD HI-FI NON-DLC)

7-3. Parts List of VCR Deck ASS’Y

LOC. PARTS CODE PARTS NAME PARTS DESCRIPTION

DRUM ASS'Y

D0010 DRUM AS (REFERRING TO LIST OF DRUM PRICE)

D0020 97SA327500 DRUM M/T AS E20XL-35

97SA327400 DRUM M/T AS DMVDMTO4M1

D0040 7001260711 SCREW MACHINE PAN 2.6X7 MFZN

D0050 97SA320400 EARTH GROUND AS T-DRUM

D0060 97S2303600 HOLDER MAIN POM(KEPITAL F20)

D0070 97S2303800 HOLDER CAP(B) POM(4CH)

D0070 97S2303900 HOLDER CAP(C) POM(6CH)

DECK ASS'Y

AM001 DECK AS (REFERRING TO LIST OF DRUM PRICE)

A0100 97SA318100 MAIN BASE AS T-MECHA

A0200 97SA316500 S SLANT POLE AS T-MECHA

A0300 97SA316600 T SLANT POLE AS T-MECHA

A0400 97S8102300 MOTOR CAPSTAN DMVCMC08D

97S8102100 MOTOR CAPSTAN F2QSB-53(PWM)

A0401 97S3102000 SCREW TAPPTITE TT2 BIN-P 2.6X7 MFZN

A0600 97SA320500 AC HEAD AS T-MECHA

A0601 7051300611 SCREW MACHINE PAN 3X6 SW MFZN

A1000 97SA316800 L LOADING AS T-MECHA

A1100 97SA316900 R LOADING AS T-MECHA

A1200 97S2709500 RACK LOADING SECC T1.2

A1201 7008301911 SCREW MACHINE WAS M3*19 MFZN
