6.2 Bed Position Save & Recall
z POS1 & POS2 Button (Position Recall)
9 Press the POS1 button to recall the programmed bed
position 1. The bed moves automatically until the head
and foot position reached to the programmed Position 1
saved.
9 Press the POS2 button to recall the programmed bed
position 2. The bed moves automatically until the head
and foot position reached to the programmed Position 2
saved.
9 If any button on the hand control excluding POS1 or
POS2 button is momentarily pressed while the bed is
moving, the bed is stop and the pressed button’s
function is not engaged.
z SET Button (Position Memory)
9 To save the current bed position as Position 1, press
SET and POS1 button in sequence. The current bed
position is saved as Position 1.
9 To save the current bed position as Position 2, press
SET and POS2 button in sequence. The current bed
position is saved as Position 2.
 Position data in Memory
Bed position data is saved in RAM of control box and is
kept until the power is supplied.
When the power of control box is turned of, position
data are cleared to zero.
