User's Manual

21
General Specification
Adjust the displayed size.(0~8)OVER SCAN
Change the image setting. (Preset 1,2 / User 1,2,3)
IMAGE SETTING
Change the secondary input source.SOURCE
Change the PIP size. (Small, Large)SIZE
Change the layout. (Single, PIP, PBP1, PBP2)LAYOUT
PIP
Change the PIP position.POSITION
Swaps the position of the Primary and Secondary images.SWAP
Change the name of a Preset to the Users Name, etcUSER NAME
ENTRY
SETUP
Adjust time until the OSD Menu will disappear after adjusting the menu. (5,
10, 20, 30, 60, 90, 120, 180, 240 seconds)
DURATION
Change the OSD position ( 9 positions )OSD POSITION
Change the OSD language (8 language)LANGUAGE
Changes the all OSD value to factory outgoing status.
RESET SETTINGS
Disable of enable auto source select.
(ON: Searches through all possible input source until an active video source
is found. OFF: Video input is manually selected.)
AUTO SOURCE
SELECT
Enlarge the image, move image left and rightZOOM / PAN
Adjust backlight dimming level (Range : 0~100)BACKLIGHT
Keep still the imageFREEZE FRAME
Set the sharpness of image (Softest, Soft, Normal, Sharp, Sharpest)FILTER
Green balance (Only works with USER mode) (Range : 0~100)GREEN
Red balance (Only works with USER mode) (Range : 0~100)RED
Blue balance (Only works with USER mode) (Range : 0~100)BLUE
Adjust GAMMA value (VIDEO,BYPASS,1.8,2.0,2.2,2.4,2.6,PACS)GAMMA
Change the image size (Full, Fill aspect, 1:1, Normal, Anamorphic)IMAGE SIZE
Change the color temperature mode ( 6500K, 5600K, USER )MODE
COLOR TEMP
Increase or decrease the contrast (Range : 0~100)CONTRAST
Changes the richness of color (Range : Green 0~50, Red 0~50)COLOR
Changes the tone of color (Range : 0~100)SATURATION
Increase or decrease the brightness (Range : 0~100)BRIGHTNESS
ADJUST
Function DescriptionsSub-menusMenus
5.2.5 SDI input source
