General Specification
148.50060.00067.5001920 x 1080 @60Hz
162.00060.00075.000
1600 x 1200 @60Hz
154.12559.99974.099
1920 x 1200 @60HZ
148.50085.00285.9381280 x 960 @85Hz
94.200
70.01663.955
1152 x 864 @70Hz
80.00060.05354.3481152 x 864 @60Hz
130.37559.98174.077
1600 x 1200 @60Hz (**)
157.50085.02491.1461280 x 1024 @85Hz
135.00075.02579.9761280 x 1024 @75Hz
108.50060.01363.9741280 x 1024 @60Hz
94.50084.99768.6771024 x 768 @85Hz
75.00070.06956.4761024 x 768 @70Hz
65.00060.00448.3631024 x 768 @60Hz
108.00060.00060.0001280 x 960 @60Hz
108.00075.00067.5001152 x 864 @75Hz
78.75075.02960.0231024 x 768 @75Hz
Pixel clock
(MHz)
Vertical
frequency
(Hz)
Horizontal
frequency
(KHz)
Resolution
(**) Preferred Timing for 1600 x 1200 @60Hz input
