Owner`s manual

6
Transmitter
PARTS & FUNCTIONS
Button #2*
(Vib.+Stim.)
Battery
Charging
Receptacle
Intensity Dial
Collar Selecting
Switch
Momentary ‘Nick’
Stimulation
Continuous
Stimulation
Red LED Indicator
Light
Button #1*
(Vibration)
*The CDT 1000 PLUS will not
have the #1 or #2 buttons.
Lanyard Loop
Transmitter Antenna
Transmitter Indicator Light
When one of the buttons on the transmitter is pushed,
the Red LED light will turn on to indicate that the
transmitter is being operated. When the battery needs
charging, the Red LED light will blink rapidly after
pressing any transmitter button. The Red LED light
will stay on solid while plugged into the charger.
