CDT PLUS Series Electronic Dog Trainer Owner’s Manual • CDT 1000 PLUS • CDT 2000 PLUS Manufactured by:
TABLE OF CONTENTS • Table of Contents ....................................... 3 • Introduction ................................................ 4 • Package Contents ...................................... 5 • Model Features .......................................... 5 • Parts & Functions ....................................... 6 • Charging the Batteries................................ 10 • Turning ON and OFF.................................. 11 • Testing .......................................
INTRODUCTION Congratulations and thank you for purchasing our Cabela’s Exclusive Alpha Dog Series CDT PLUS Training Collar with “Add-On” capability. The Cabela’s Alpha Dog Series represents the absolute latest technological advancement in the Electronic Dog Training World. It offers Maxx-Range™, the industry’s only internally woven antenna in the collar. With up to a 1200 yard range, they are perfect for hunting, basic obedience and professional training.
PACKAGE CONTENTS • • • • • • • • Transmitter Collar Receiver Antenna for the Transmitter Rechargeable NiMH Batteries for both the Collar and Transmitter (already installed) Battery Charger Splitter Cable for simultaneous charging Test Light Owner’s Manual MODEL FEATURES CDT PLUS Series • Digital Technology • Up to 1200 yard (2/3 mile) range • Expandable to 2- or 3-dog system with CDT PLUS • • • • • • • • Add-On collar units (sold separately) Lightweight, waterproof collar Weather resistant transmitter 1
PARTS & FUNCTIONS Transmitter Antenna *The CDT 1000 PLUS will not have the #1 or #2 buttons. Lanyard Loop Red LED Indicator Light Collar Selecting Switch Intensity Dial Button #2* (Vib.+Stim.) Button #1* (Vibration) Momentary ‘Nick’ Stimulation Continuous Stimulation Battery Charging Receptacle Transmitter Transmitter Indicator Light When one of the buttons on the transmitter is pushed, the Red LED light will turn on to indicate that the transmitter is being operated.
PARTS & FUNCTIONS Intensity Selection Dial The intensity selection dial can be set from level 1 to level 16 to find the exact stimulation level for your dog (see page 15). Collar Selecting Switch Switching between collar units can be controlled by moving the Collar Selection Switch to the desired unit. Transmitter Antenna Always check that the antenna is securely fastened to the transmitter before each use. Hand tighten only. Use care when attaching antenna.
PARTS & FUNCTIONS Collar Belt with MAXX-Range™ Antenna Contacts LED Indicator Light Charging Receptacle ON/OFF Button Collar Receiver Collar Belt with MAXX-Range™ Antenna The embedded collar antenna is woven into the collar belt, and runs along the entire length of the belt. This antenna wraps around your dog’s neck and will give your collar unit 360˚ of signal reception no matter which way your dog is facing.
PARTS & FUNCTIONS Collar LED Indicator Light When the Collar Receiver is turned on, the Red LED light will flash steadily once every two seconds to indicate that the unit is active. The Red LED light changes to a rapid flash when the battery is in need of charging. The Red LED light stays lit while plugged into the charger. Contacts Contacts should fit snugly against the dog’s neck to ensure good contact with the skin. For more information on the proper fit of the collar, see page 14.
CHARGING THE BATTERIES All CDT PLUS Series units are equipped with rechargeable Nickel Metal Hydride (NiMH) batteries. NiMH batteries are not memory sensitive and do not require depletion before recharging. The batteries come partially charged from the factory. However, it is recommended that the batteries are given a full charge (about 12 hours) before initial use. Remember - Always keep batteries away from flammable substances (especially when charging).
CHARGING THE BATTERIES NOTE Rechargeable batteries typically last about 2-5 years on average depending on use and care. Do not overcharge your unit (12 hour maximum charge time). Do not store your unit without a charge for extended periods of time. Do not store your unit in extreme heat/cold or moist/humid conditions. TURNING ON AND OFF The Transmitter is always in a permanent sleep state. It is only ON when a button is being pressed and does not need to be turned off by the user.
TESTING NOTE: Before testing, make sure that both units are fully charged and the power to the Collar Receiver is “ON”. To Test the Electronic Stimulation: A) Place the tester firmly on the contacts of the Collar Receiver. B) Set the intensity (note - an intensity level setting of 4 or less might not be enough to light the tester). C) Push the ‘NICK’ or ‘CONT’ button.
PROGRAMMING THE COLLAR When adding an “Add-On” collar, the collar will need to be programmed to the transmitter. If your current collar unit is not responding to the transmitter, it may also need to be reprogrammed to the transmitter. 1. Select the desired Collar Selecting Switch position on the transmitter. 2. Press and hold the power button on the collar like the collar unit is being turned ON. 3.
PROPERLY FITTING THE COLLAR NOTE: Proper collar tightness and position are very important to insure safe and consistent collar use. All electronic collars need to be very snug around the dog’s neck to work properly. They must be just tight enough to allow the “contacts” or electrodes to make good contact on your dog’s skin. If the collar is too loose, the stimulation may not work properly because good/ consistent skin contact is not being achieved.
SETTING THE INTENSITY LEVEL It is very important to set the correct intensity level on your CDT PLUS Training System before beginning your training sessions to provide the proper level of stimulation without over-stimulating your dog. To do this, place the Intensity Selection dial so that the system is set on Level 1. Turn on the Collar and then fit it properly around your dog’s neck. Press either the ‘NICK’ or the ‘CONT’ Button and check for a reaction.
MAINTENANCE It is very important to periodically clean your CDT PLUS Series systems for maximum performance. Regular cleaning will also lengthen the life of your unit. • Clean the CDT PLUS Series collar box with lukewarm water and a mild anti-bacterial soap. • Take care to thoroughly clean the space between the electrodes and the belt. • The belt and buckle should be cleaned with water and a mild soap then allowed to dry completely. • Always allow the entire unit to completely dry before using.
IMPORTANT SAFETY NOTES • Before training, your dog should be examined by a veterinarian to assure that your dog is in good health. • Never leave your dog unattended with the unit on. Since no electronic device is perfect, there is a very slight possibility that your dog may receive an unintentional electric stimulation. • Your CDT PLUS Series training collar is a very valuable tool if used correctly.
WARRANTY • D.T. Systems Premium Lifetime Warranty is the best warranty offered in the industry. This warranty is free to participating U.S. customers (a completed warranty registration card must be returned within 30 days of original purchase). This changes our normal one year parts and labor warranty to a limited lifetime warranty against manufacturing defects on parts and a one year warranty on labor.
FCC/IC/CE COMPLIANCE Your CDT PLUS Series TM Trainer has been manufactured under complete compliance with Part 15 of the Federal Communication Commission (FCC) rules and Industry Canada (IC) Standard RSS-310. The complex internal structure of each product has been designed to operate within specific regulations of FCC specifications. Any changes or modifications not expressly approved by the manufacturer is a violation of these specifications and could void the user's authority to operate the equipment.
2872 Walnut Hill Lane Dallas, Texas 75229 Tel: (214) 350-9446, (888) 588-8364 Fax: (214) 350-7847 Website: www.dtsystems.com E-mail: customerservice@dtsystems.com 1-CDT PLUS 2011.03.
