A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 77 -
10.10 DSP card
The DSP card adds mixing capabilities to your 19” rack. In combination with the Axum
engine, this card gives you 32 stereo processing channels to create a mixing desk.
The system may be loaded with four DSP cards, which generates a mixing console with
128 stereo channels.
The ACT(ive) LED blinks when this card functions properly.
