7.1.1.3 Clock
To change the time zone, click on the used time zone (in our example ‘Europe/Amsterdam’). You can
select the desired time zone in the list box.
The AXUM uses the NTP protocol for accurate clock synchronization. In the section ‘current’ you find
the IP address of the used ‘clock master’ and its ‘stratum’. For more information on NTP:
http://en.wikipedia.org/wiki/Network_Time_Protocol
When IP and DNS settings are setup correct, the AXUM will automatically synchronize to a pool of
time servers. The AXUM is also able to use a GPS receiver via USB for time synchronization. next,
the AXUM may function as a NTP server for the surfaces. There for, on the webserver of the control
surfaces you can configure the 'optional ntp server' and fill in the IP address of the ntp server (e.g.
192.168.0.200).
Set date/time may be used on system without any synchronization to set the correct time.
In the popup window it is possible to give to correct time and if you click on the ‘day’ it will become
direct changed/activated.
Remember that all other changes (NTP and IP settings) will become effective after reboot.
