A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 48 -
• Console preset
It is possible to select a console preset which will be loaded if the user logs in.
• Pool
Per console you can select which preset and which source pool the user may use. Per pool
you can choose between A, B or all. (see also 6.1.16 Source pools and 6.1.17 Preset pools)
• Delete
When you click on this column the user will be deleted.
Create new user
By clicking on this link a popup will appear where you have to setup the username and password for
the new user.
