(this field is only available when the destination-level function is also assigned to an object;
e.g. via rack configuration)
• Default signal from
This destination/output will send audio from the default selected source (except if a N-1 is
active, then automatically the N-1 signal is selected).
You can choose:
- Input sources (Mic, line, dig etc. etc.)
- Mix busses
- Monitor busses
- Insert outs (of modules)
• Default signal routing
Here you can choose which signal feeds the physical outputs:
Stereo (if no mix minus source is assigned):
Output left and right received their corresponding signal
Left:
Output left and right both receive the left signal.
Right:
Output left and right both receive the right signal.
Mono (only if a mix minus source is assigned):
The mix minus signal is always a mono signal.
• N-1 from/mix minus source
When the selected source is assigned to a module, this destination automatically creates an
N-1 using the selected source. There is no limitation on the amount of N-1s, every module is
able to make its own N-1.
• Delete
When you click on this column the destination will be deleted (and also all references are
deleted).
• Create a new destination
By clicking on this link a popup will appear where you have to setup the physical outputs and
label for the new destination. When you select the same output for both channels, the system
will use it on the left output and set the right to none.
