20.2 Busses
The Axum has 16 stereo busses. For each buss, you are able to connect objects with the following
functions:
Function name
comments
Object to connect to
Version
Buss master level
Controls the buss master level
Encoder, Fader
2.0
Buss master level reset
Select ‘On and 0 dB’
Encoder switch
2.0
Buss master on/off
Select buss on/off
Switch
2.0
Buss master pre Switches the total buss pre or post Switch 2.0
Buss Label
Label of the buss
Display
2.0
Buss Audio level left
Left audio level of the buss
Level meter
2.0
Buss Audio level right Right audio level of the buss Level meter 2.0
Buss Audio phase
Phase between buss left/right
Phase meter
2.3
Select 1
When buss select for console 1 is
activated the current buss will be
selected
meter-selector
2.3
Select 2
When buss select for console 2 is
activated the current buss will be
selected
meter-selector
2.3
Select 3
When buss select for console 3 is
activated the current buss will be
selected
meter-selector
2.3
Select 4
When buss select for console 4 is
activated the current buss will be
selected
meter-selector
2.3
Reset
Resets all routing to this buss
PFL-reset button
2.5
Talkback 1
Switches all destinations to
talkback 1 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 2
Switches all destinations to
talkback 2 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 3
Switches all destinations to
talkback 3 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 4 Switches all destinations to
talkback 4 if this buss is the ‘signal
from’ buss
Switch 2.5
Talkback 5 Switches all destinations to
talkback 5 if this buss is the ‘signal
from’ buss
Switch 2.5
Talkback 6 Switches all destinations to
talkback 6 if this buss is the ‘signal
from’ buss
Switch 2.5
Talkback 7
Switches all destinations to
talkback 7 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 8
Switches all destinations to
talkback 8 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 9
Switches all destinations to
talkback 9 if this buss is the ‘signal
from’ buss
Switch
2.5
Talkback 10
Switches all destinations to
talkback 10 if this buss is the
‘signal from’ buss
Switch
2.5
Talkback 11
Switches all destinations to
talkback 11 if this buss is the
‘signal from’ buss
Switch
2.5
Talkback 12
Switches all destinations to
talkback 12 if this buss is the
‘signal from’ buss
Switch
2.5
Talkback 13
Switches all destinations to
talkback 13 if this buss is the
‘signal from’ buss
Switch
2.5
Talkback 14
Switches all destinations to
talkback 14 if this buss is the
‘signal from’ buss
Switch
2.5
