MODEL
DWC-540DV
Image Sensor 1/3” DPS ORCA
Effective Pixels 720(h) x 540 (v)
Horizontal Resolution Max 540 TV Lines
Scanning Frequency 15.734KHz(H), 59.944(V)
Video Io Select NTSC / PAL
Min. Illumination Color : 0.4 Lux ( F:1.2),
( Sense-up 32x : 0.08Lux) )
Day & Night D&N Function by Digital Change : Auto/Off
White Balance Auto /AWB / Manual
DSS Off / 2 fields ~ 32 fields
DNR Auto / High / Low
Lens 2.9mm~10mm DC auto iris lens
AGC Low / Auto / High / Off
Wide Dynamic Range Max 120dB /17 –bit
Camera ID On / Off
S/N Ratio More than 50dB
Video Output Composite video output 75 ohm terminated
OSD Built-in
Sync. System Internal
Operating Humidity 30 % ~ 90 % RH
Operating Temp. - 10°C to 50°
Dimension 145(D)X103(H)mm
Weight About 1.2Kg
Material Aluminum body, PC bubble(100mm)
Power Consumption 250mA
Power Supply DC 12 V(10.2V~14.5 V)
AC 24V (Option)
9. SPECIFICATIONS
