Super Wide Dynamic Range Vandal Dome Color Camera 사용 설명서 MANUAL 용 서 DWC-540DV
The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not install the camera on a surface that can not support it. Unless the surface is suitable, it could cause falling or other hazards. Do not hold plug with wet hands. It could cause an electric shock. Do not disassemble the camera.
■ Contents 1.Features -------------------------------- 5 2. Components & Cable Connection --------------------------------- 6 3. Names and functions of parts --------------------------------- 7 4. Installation --------------------------------- 8 5. Setup Menu flow -------------------------------- 9 6. Setup page menu --------------------------------- 11 7. Special page 1 menu --------------------------------- 16 8. Special page 2 menu --------------------------------- 19 8.
1.
2.
3. Names and Functions of Parts 1) Names and functions of parts ① ② ③ ① Lens : Vari-Focal Auto Iris Lens ( 2.9mm ~10.0mm / F1.2 ) ② OSD PCB - Setup button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. - Up & Down buttons : Used for selecting items by moving the cursor up or down on the menu screen.
4.
5.
2) Special Page 1 Menu SPECIAL PAGE 1 CAMERA ID DAY&NIGHT SYNC MOTION DETECTION ZOOM PT BACKLIGHT AE PREFERENCE OFF ON CAMERA ID POSITION OFF AUTO ON INT EXT OFF ON OFF ON OFF ON LIGHTS SHADOW SAVE & RETURN PAGE 2 3) Special Page 2 Menu MIRROR FREEZE SHARPNESS FLICKERNESS FLUORESCENT LIGHT FACTORY RESET SYSTEM INFORMATION SAVE & RETURN PAGE 1 SPECIAL PAGE 2 OFF ON OFF 15 Frms SET FREEZE - 8 -------▪-------- 8 OFF ON ON OFF FW Rev 10 UP-DOWN UP-CENTER UP-RIGHT DOWN-LEFT DOWN-CENTER DOWN-RIGHT
6. SETUP PAGE MENU 1. LENS & VIDEO I/O SET SETUP PAGE ▶LENS & VIDEO I/O SETUP LENS DC VIDEO MANUAL VIDEO NTSC PAL RESOLUTION HIGH WDR AUTO WB CONTROL AUTO AGC AUTO DNR AUTO SENS & MOTION-UP DSS CONTROL EXIT • Lens Choose the lens type DC, Video and manual lens by using the selector button. • Video I/O Choose video system between PAL and NTSC by moving the selector. 2. RESOLUTION Choose resolution between high and normal with the selector (right/left).
4. WB CONTROL (White Balance Modes) White Balance is a function which compensates different colors of light being emitted from different light sources. Users can select the above levels as they desire according to the environment. SETUP PAGE LENS & VIDEO I/O SETUP RESOLUTION HIGH WDR AUTO ▶WB CONTROL AUTO ATWDes AWC MANUAL AGC AUTO DNR AUTO SENS & MOTION-UP DSS CONTROL EXIT • AUTO (Auto Tracking White Balance) The Auto Tracking White Balance (ATW) mode continuously monitors color temperature.
6. DNR DNR is Digital Noise Reduction System with a maximum gain of 24 DB. SETUP PAGE LENS & VIDEO I/O SETUP RESOLUTION HIGH WDR AUTO WB CONTROL AUTO AGC AUTO ▶DNR AUTO OFF SENS & MOTION-UP DSS CONTROL EXIT • By Setting it to AUTO Mode, Noise Will be Little & OFF Mode Vice versa. 7. SENS & MOTION-UP You can control DSS levels and speed levels of camera to optimize the camera condition in this mode.
• WHITE BALANCE SPEED ① ATW Slew ATW slew controls the rate of change when transitioning from one color thmperature to another, An example of this would be panning the camera from an indoor fluorescent scene of 4000K out a window to a daylight scene of 6500K. The slew property tells the camera how fast to make the adjustment from 4000K to 6500K. The property itself is a value from 1 to 100, with I being the fastest slew and 100 being the slowest.
fast or too small. If a change in meter reading is substantially enough to pass through these two blocks, the camera will respond. Then it’s a question of how quickly the camera will respond—which is the purpose of the next block. ③ Trans The role of the transition block is to control the rate of the transition from old to new camera settings. They control how big a transition can be made from the current setting to the target setting at each step.
7. SPECIAL PAGE 1 MENU 1. CAMERA ID User can enter a unique name for the respective camera. The maximum length of the ID is eight characters. SPECIAL PAGE 1 ▶CAMERA ID OFF ON. DAY&NIGHT OFF SYNC INT MOTION OFF ZOOM PT OFF BACKLIGHT OFF AE PREFERENCE LIGHTS SAVE & RETURN • You can choose the ON and OFF with the selector.If you select ON, the entered camera ID is displayed at the selected position in the video picture (normal operation). • Please select the setup button while in ON mode.
SPECIAL PAGE 1 CAMERA ID OFF DAY&NIGHT OFF SYNC INT ▶MOTION DETECTION OFF ON ZOOM PT OFF BACKLIGHT OFF AE PREFERENCE LIGHTS SAVE & RETURN MOTION DETECTION ACTIVITY THRES 0 ------------ 100 DIGITAL ZOOM 1-------------- 4 DIGITAL PAN -100 -------------- 100 DIGITAL TILT -100--------------- 100 SETUP MOTION DETECTION ZONE PREVIOUS PAGE - Off : Motion detection mode is cancelled. - On : Any motion in the selected areas is observed. - Please select the setup button while in ON mode.
7. AE PREFERENCE The camera user has a choice to optimize the scene when high dynamic range lighting is detected by setting the Automatic Exposure Preference. SPECIAL PAGE 1 CAMERA ID OFF DAY&NIGHT OFF SYNC INT MOTION OFF ZOOM PT OFF BACKLIGHT OFF ▶AE PREFERENCE LIGHTS SHADOW SAVE & RETURN • SHADOW When AE Preference is set to shadow, the camera will adjust the exposure so that dark parts of the image are most visible; bright parts of the image may saturate.
8. SPECIAL PAGE 2 MENU 1. MIRROR Select “OFF” to show the image as normal. Select “ON” to reflect image horizontally. SPECIAL PAGE 2 ▶MIRROR FREEZE SHARPNESS FLICKERNESS FLUORESCENT LIGHT FACTORY RESET SYSTEM INFORMATION SAVE & RETURN OFF ON OFF - 8 --▪-- 8 OFF ON FW Rev 2. FREEZE When frame repeat count is set to 0, the same image continues to repeat until the property value is changed. This has the effect of a “freeze frame.
4. FLICKERNESS ON/OFF The slow shutter mode can be used manually to reduce flicker caused from fluorescent lights when line lock synchronization is not available. SPECIAL PAGE 2 MIRROR FREEZE SHARPNESS ▶FLICKERNESS FLUORESCENT LIGHT FACTORY RESET SYSTEM INFORMATION OFF ON OFF - 8 --▪-- 8 OFF ON ON • When Flickerness set to OFF, trembleming is reduced ( Default). • When Flickerness set to ON, trembling is increased FW Rev 5.
9. SPECIFICATIONS MODEL DWC-540DV Image Sensor 1/3” DPS ORCA Effective Pixels 720(h) x 540 (v) Horizontal Resolution Max 540 TV Lines Scanning Frequency 15.734KHz(H), 59.944(V) Video Io Select NTSC / PAL Min. Illumination Color : 0.4 Lux ( F:1.2), ( Sense-up 32x : 0.08Lux) ) Day & Night D&N Function by Digital Change : Auto/Off White Balance Auto /AWB / Manual DSS Off / 2 fields ~ 32 fields DNR Auto / High / Low Lens 2.
