User's Manual

62D-Link DIR-645 User Manual
Section 3 - Software Configuration
Step 2: In the second step, the user can configure the schedule settings for this rule.
The following parameters will be available for configuration:
Details:
Select the appropriate predefined schedule rule to apply to
this rule from the drop-down menu.
Step 3: In the third step, the user can configure the address type and IP address of
the machines used in this rule.
The following parameters will be available for configuration:
Address Type:
Specify a machine with its IP or MAC address, or select
‘Other Machines’ for machines that do not have a policy.
IP Address:
After selecting the IP address type, the user can enter the IP
address of the machines used in this rule here. Alternatively,
the user can select a Computer from the Computer Name
list.
Machine Address:
After selecting the MAC address type, the user can enter
the MAC address of the machine used in this rule here.
Alternatively, the used can select a Computer from the
Computer Name list.
Add:
Click on this button to add the machine to the list.
Update:
After clicking the option, the user will be able to update the machine information.
Delete:
If the user chooses to remove a machine from the list, click on the icon.
Step 4: In the fourth step, the user can select the filtering method used for this rule.
The following parameters will be available for configuration:
Method:
Here the user can select the filtering method used. Options
to choose from are ‘Log Web Access Only’, ‘Block All
Access’, and ‘Block Some Access’.
