Section 3 - Software Configuration
My Internet Connection is: DS-Lite)
Another Internet Connection type is DS-Lite.
After selecting DS-Lite, the following parameters will be available for configuration:
DS-Lite
Configuration:
Select the DS-Lite DHCPv6 Option to let the router
allocate the AFTR IPv6 address automatically. Select the
Manual Configuration to enter the AFTR IPv6 address in
manually.
AFTR IPv6
Address:
After selecting the Manual Configuration option above, the
user can enter the AFTR IPv6 address used here.
B4 IPv4 Address:
Enter the B4 IPv4 address value used here.
WAN IPv6
Address:
Once connected, the WAN IPv6 address will be displayed
here.
IPv6 WAN Default
Gateway
Once connected, the IPv6 WAN Default Gateway address will
be displayed here.
Click on the Save Settings button to accept the changes made.
Click on the Don’t Save Settings button to discard the changes made.
