Specifications

Section 1 - Product Overview
D-Link DSL-320B User Manual
5
•
Hardware Overview
Connections
Power Insert
Use the adapter shipped with the
Modem to connect to power
source.
Power Button
Push in to power-on the Modem
Push again to power-off the
Modem.
Ethernet Port
Use the Ethernet port to connect
the Modem to a computer or an
Ethernet LAN.
ADSL Port
Use the ADSL cable to connect
to the your telephone line (RJ-11
port).
Reset Button
To manually reset, depress
button with the power on for a
t
least seven seconds.
