Bridge Mode

For Bridged connections it will be necessary for most users to install

additional software on any computer that will use the Modem for Internet

access. The additional software is used for the purpose of identifying

and verifying your account, and then granting Internet access to the

computer requesting the connection. The connection software requires

the user to enter the User Name and Password for the ISP account. This

information is stored on the computer, not in the Modem.

To configure a Static IP Address WAN connection, follow these steps:

1. Choose the Connection Type from the drop-down menu. This

defines both the connection protocol and encapsulation method

used for your ADSL service. The available options are 1483

Bridged IP LLC and 1483 Bridged IP VC-Mux. If you have not

been provided specific information for this setting, leave the

default setting.

2. If you are instructed to change the VPI or VCI values, type in the

values assigned for your account.

3. When you are satisfied that all the WAN settings are configured

correctly, click the Apply Settings button. This will save the

settings and reboot the Modem to let your changes take effect.

4. Upon restarting, the Modem should automatically establish the

WAN connection.
