DAP-2553 User’s Manual
D-Link AirPremier N Dual Band PoE Access Point
Select Enable or Disable.
When you select Open System, toggle between Enable and
Disable.IfEnable is selected, the Key Type, Key Size, Key Index
(1~4), Key, and Confirm Keys must also be configured.
Select HEX or ASCII.
Select 64 Bits or 128 Bits.
Select from the 1st to 4th key to be set as the active key.
Input up to four keys for encryption.You will select one of these keys
in the Key Index pull-down menu.
Key Type:
Key Size:
Key Index (1~4):
Key:
WMM (Wi-Fi Multimedia):
The Multi-SSID security can be Open System, WPA-Personal, or
WPA-Enterprise
. For a detailed description of the Open System
parameters please go to pages 23-24. For a detailed description of
the WPA-Personal parameters please go to page 25. For a detailed
description of the WPA-Enterprise parameters please go to pages
26-27.
Security:
Encryption:
Cipher Type:
Group Key Update
Interval:
Select the interval during which the group key will be valid. The
default value of 1800 seconds is recommended.
Select Auto, AES, or TKIP from the pull-down menu.
PassPhrase:
When you select WPA-Personal, please enter a PassPhrase in the
corresponding field.
Using the Configuration Menu
SSID Visibility:
Enable or Disable SSID visibility. Enabling this feature broadcasts
the SSID across the network, thus making it visible to all network
users.
Confirm PassPhrase:
When you select WPA-Personal, please re-enter the PassPhrase
entered in the previous item in the corresponding field.
RADIUS Server:
When you select WPA-Enterprise, enter the IP address of the
RADIUS server. In addition, you must configure RADIUS Port and
RADIUS Secret.
RADIUS Port:
Enter the RADIUS port.
When you select either WPA-Personal or WPA-Enterprise,you
must also choose a WPA mode from the pull-down menu: AUTO
(WPA or WPA2)
, WPA2 Only,orWPA Only. WPA and WPA2 use
different algorithms. AUTO (WPA or WPA2) allows you to use both
WPA and WPA2. In addition, you must configure Cipher Type, and
Group Key Update Interval.
WPA Mode:
RADIUS Secret:
Enter the RADIUS secret.
