User's Manual

25
DAP-2553 User’s Manual
D-Link AirPremier N Dual Band PoE Access Point
Home > Basic Settings > Wireless > WPA-Enterprise
authentication
Cipher Type:
Group Key Update
Interval:
When WPA-Enterprise is selected, you must also select a cipher
type from the pull-down menu: Auto, AES,orTKIP.
Select the interval during which the group key will be valid.
1800 is the recommended value as a lower interval may reduce
data transfer rates.
Using the Configuration Menu
When WPA-Enterprise is selected, you must also select a WPA
mode from the pull-down menu: AUTO (WPA or WPA2), WPA2 Only,
or WPA Only.WPA and WPA2 use different algorithms. AUTO (WPA
or WPA2)
allows you to use both WPA and WPA2.
WPA Mode:
RADIUS Server:
Enter the IP address of the RADIUS server.
RADIUS Port:
Enter the RADIUS port.
RADIUS Secret:
Enter the RADIUS secret.
Enable or disable Microsoft Network Access Protection.
Network Access Protection:
