5.0 PRODUCT SPECIFICATION
UC00C is designed to ease communication between microcontroller and PC. The
specifications are as listed below:
5.1 6 ways header socket
Label
Definition
Function
DTR
UC00C Data Terminal
Ready pin
In Arduino compatible board, this pin is use for
auto-reset.
RX
UC00C UART Receive
pin
This is UC00C receiver pin. It should be connected to
device’s transmitter pin.
TX
UC00C UART
Transmit pin
This is UC00C transmitter pin. It should be connected
to device’s receiver pin.
Vsel
3.3V or 5V power
output from UC00C
Power output from UC00C to connect to
microcontroller. The optional power output is 3.3V or
5V. If 5V is selected at Vsel jumper, this pin will supply
5V to target device.
CTS
UC00C Clear To Send
pin
Hardware Hand-shacking pin.
GND
Ground or negative
Ground of power and signal. This pin should be
connected to device’s GND pin.
