 ProductUser’sManual–SHIELDMD10


3.0PRODUCTSPECIFICATIONANDLIMITATIONS

AbsoluteMaximumRating
Parameter
Min
Typical
Max
Unit
PowerInputVoltage(Motorsupplyvoltage)
7

25
V
IMAX(MaximumContinuousMotorCurrent)


10
A
IPEAK(PeakMotorCurrent)*


15
A
VIOH(LogicInputHighLevel)
3

5.5
V
VIOL(LogicInputLowLevel)
0
0
0.5
V
MaximumPWMFrequency


10
KHz
*Mustnotexceed10seconds

 
