CY7C67300
Document #: 38-08015 Rev. *J Page 74 of 99
UART Status Register [0xC0E2] [R]
Register Description
The UART Status register is a read only register that indicates
the status of the UART buffer.
Receive Full (Bit 1)
The Receive Full bit indicates whether the receive buffer is full.
It can be programmed to interrupt the CPU as interrupt #5 when
the buffer is full. This can be done though the UART bit of the
Interrupt Enable register (0xC00E). This bit is automatically
cleared when data is read from the UART Data register.
1: Receive buffer full
0: Receive buffer empty
Transmit Full (Bit 0)
The Transmit Full bit indicates whether the transmit buffer is full.
It can be programmed to interrupt the CPU as interrupt #4 when
the buffer is empty. This can be done though the UART bit of the
Interrupt Enable register (0xC00E). This bit is automatically set
to ‘1’ after data is written by EZ-Host to the UART Data register
(to be transmitted). This bit is automatically cleared to ‘0’ after
the data is transmitted.
1: Transmit buffer full (transmit busy)
0: Transmit buffer is empty and ready for a new byte of data
UART Data Register [0xC0E4] [R/W]
Register Description
The UART Data register contains data to be transmitted or
received from the UART port. Data written to this register starts
a data transmission and also causes the UART Transmit Full
Flag of the UART Status register to set. When data received on
the UART port is read from this register, the UART Receive Full
Flag of the UART Status register is cleared.
Data (Bits [7:0])
The Data field is where the UART data to be transmitted or
received is located.
Reserved
Write all reserved bits with ’0’.
Table 122. UART Status Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved...
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field ...Reserved Receive Full Transmit Full
Read/Write - - - - - - R R
Default 0 0 0 0 0 0 0 0
Table 123. UART Data Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field Data
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
