CY7C67300
Document #: 38-08015 Rev. *J Page 73 of 99
Register Description
The SPI Receive Count register designates the block byte length
for the SPI receive DMA transfer.
Count (Bits [10:0])
The Count field sets the count for the SPI receive DMA transfer.
Reserved
Write all reserved bits with ’0’.
UART Registers
There are three registers dedicated to UART operation. Each of
these registers is covered in this section and summarized in
Table 119.
UART Control Register [0xC0E0] [R/W]
Register Description
The UART Control register enables or disables the UART,
allowing GPIO28 (UART_TXD) and GPIO27 (UART_RXD) to be
freed up for general use. This register must also be written to set
the baud rate, which is based on a 48 MHz clock.
Scale Select (Bit 4)
The Scale Select bit acts as a prescaler that divide the baud rate
by eight.
1: Enable prescaler
0: Disable prescaler
Baud Select (Bits [3:1])
Refer to Table 121 for a definition of this field.
UART Enable (Bit 0)
The UART Enable bit enables or disables the UART.
1: Enable UART
0: Disable UART. This allows GPIO28 and GPIO27 to be used
for general use.
Reserved
Write all reserved bits with ’0’.
Table 119. UART Registers
Register Name Address R/W
UART Control Register 0xC0E0 R/W
UART Status Register 0xC0E2 R
UART Data Register 0xC0E4 R/W
Table 120. UART Control Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved...
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field ...Reserved Scale Select Baud Select UART Enable
Read/Write - - - R/W R/W R/W R/W R/W
Default 0 0 0 0 0 1 1 1
Table 121. UART Baud Select Definition
Baud Select
[3:1]
Baud Rate w/ DIV8 = 0 Baud Rate w/ DIV8 = 1
000 115.2 KBaud 14.4 KBaud
001 57.6 KBaud 7.2 KBaud
010 38.4 KBaud 4.8 KBaud
011 28.8 KBaud 3.6 KBaud
100 19.2 KBaud 2.4 KBaud
101 14.4 KBaud 1.8 KBaud
110 9.6 KBaud 1.2 KBaud
111 7.2 KBaud 0.9 KBaud
