CY7C67300
Document #: 38-08015 Rev. *J Page 65 of 99
Done1 Flag (Bit 2)
In host mode the Done 1 Flag bit is a read only bit that indicates
if a host packet done interrupt occurs on Host 1. In device mode
this read only bit indicates if an any of the endpoint interrupts
occur on Device 1. Firmware needs to determine which endpoint
interrupt occurred.
1: Interrupt triggered
0: Interrupt did not trigger
Reset1 Flag (Bit 1)
The Reset1 Flag bit is a read only bit that indicates if a USB
Reset interrupt occurs on either Host/Device 1.
1: Interrupt triggered
0: Interrupt did not trigger
Mailbox Out Flag (Bit 0)
The Mailbox Out Flag bit is a read only bit that indicates if a
message is ready in the outgoing mailbox. This interrupt clears
when the external host reads from the HPI Mailbox register.
1: Interrupt triggered
0: Interrupt did not trigger
SPI Registers
There are twelve registers dedicated to SPI operation. Each of these registers is covered in this section and summarized in Table 104.
Table 104. SPI Registers
Register Name Address R/W
SPI Configuration Register 0xC0C8 R/W
SPI Control Register 0xC0CA R/W
SPI Interrupt Enable Register 0xC0CC R/W
SPI Status Register 0xC0CE R
SPI Interrupt Clear Register 0xC0D0 W
SPI CRC Control Register 0xC0D2 R/W
SPI CRC Value 0xC0D4 R/W
SPI Data Register 0xC0D6 R/W
SPI Transmit Address Register 0xC0D8 R/W
SPI Transmit Count Register 0xC0DA R/W
SPI Receive Address Register 0xC0DC R/W
SPI Receive Count Register 0xC0DE R/W
