CY7C67300
Document #: 38-08015 Rev. *J Page 54 of 99
IDE Stop Address Register [0xC04C] [R/W]
Register Description
The IDE Stop Address register holds the stop address for an IDE
block transfer. This register is byte addressed and IDE block
transfers are 16-bit words, therefore the LSB of the stop address
is ignored. Block transfers begin at IDE Start Address and end
with the final word at IDE Stop Address. When IDE Start Address
equals IDE Stop Address, the block transfer moves one word of
data.
The hardware keeps an internal memory address counter. The
two MSBs of the addresses are not modified by the address
counter. Therefore the IDE Start Address and IDE Stop Address
must reside within the same 16K byte block.
Address (Bits [15:0])
The Address field sets the stop address for an IDE block transfer.
IDE Control Register [0xC04E] [R/W]
Register Description
The IDE Control register controls block transfers in IDE mode.
Direction Select (Bit 3)
The Direction Select bit sets the block mode transfer direction.
1: Data is written to the external device
0: Data is read from the external device
IDE Interrupt Enable (Bit 2)
The IDE Interrupt Enable bit enables or disables the block
transfer done interrupt. When enabled, the Done Flag is sent to
the CPU as cpuide_intr interrupt. When disabled, the cpuide_intr
is set LOW.
1: Enable block transfer done interrupt
0: Disable block transfer done interrupt
Done Flag (Bit 1)
The Done Flag bit is automatically set to ‘1’ by hardware when a
block transfer is complete. The CPU clears this bit by writing a
‘0’ to it. When IDE Interrupt Enable is set this bit generates the
signal for the cpuide_intr interrupt.
1: Block transfer is complete
0: Clears IDE Done Flag
IDE Enable (Bit 0)
The IDE Enable bit starts a block transfer. It is reset to ‘0’ when
the block transfer is complete
1: Start block transfer
0: Block transfer complete
Reserved
Write all reserved bits with ’0’.
Table 86. IDE Stop Address Register
Bit # 15 14 13 12 11 10 9 8
Field Address...
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field ...Address
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
Table 87. IDE Control Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved...
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field
...Reserved Direction
Select
IDE
Interrupt
Enable
Done
Flag
IDE
Enable
Read/Write - - - - R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
