The Device n Endpoint n Count Result register is a
memory-based register that must be initialized to 0x0000 before
USB Device operations are initiated. After initialization, do not
write to this register again.
Result (Bits [15:0])
The Result field contains the differences in bytes between the
received packet and the value specified in the Device n Endpoint
n Count register. If an overflow condition occurs, Result [15:10]
is set to ‘111111’, a 2’s complement value indicating the
additional byte count of the received packet. If an underflow
condition occurs, Result [15:0] indicates the excess bytes count
(number of bytes not used).
Reserved
Write all reserved bits with ‘0’.
Device n Port Select Register [R/W]
■ Device n Port Select Register 0xC084
■ Device n Port Select Register 0xC0A4
Register Description
The Device n Port Select register selects either port A or port B
for the static device port.
Port Select (Bit 14)
The Port Select bit selects which of the two ports is enabled.
1: Port 1B or Port 2B is enabled
0: Port 1A or Port 2A is enabled
Device n Interrupt Enable Register [R/W]
■ Device 1 Interrupt Enable Register 0xC08C
■ Device 2 Interrupt Enable Register 0xC0AC
Register Description
The Device n Interrupt Enable register provides control over
device related interrupts including eight different endpoint inter-
rupts.
VBUS Interrupt Enable (Bit 15)
The VBUS Interrupt Enable bit enables or disables the OTG
VBUS interrupt. When enabled, this interrupt triggers on both the
rising and falling edge of VBUS at the 4.4V status (only
Table 68. Device n Port Select Register
Bit # 15 14 13 12 11 10 9 8
Field
Reserved Port
Select
Reserved...
Read/Write - R/W - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field ...Reserved
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Table 69. Device n Interrupt Enable Register
Bit # 15 14 13 12 11 10 9 8
Field
VBUS
Interrupt
Enable
ID Interrupt
Enable
Reserved SOF/EOP
Timeout
Interrupt
Enable
Reserved SOF/EOP
Interrupt
Enable
Reset
Interrupt
Enable
Read/Write R/W R/W - - R/W - R/W R/W
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field
EP7 Interrupt
Enable
EP6 Interrupt
Enable
EP5 Interrupt
Enable
EP4 Interrupt
Enable
EP3 Interrupt
Enable
EP2 Interrupt
Enable
EP1 Interrupt
Enable
EP0 Interrupt
Enable
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
